OGL 200

customersupport@olympiaelevators.com Customer Care : 020-26962606 | 020-26962607

Olympia Elevators Pvt. Ltd. Service Provider of Elevator Contractors, Elevator Repair and Services - Schindler, Elevator Installation Services, Elevator Dealers, Elevators Control Modification, New Escalators Installations, Hospital Elevator, Elevators Modification, Elevators AMC, Elevators Maintenance services.

Enquiry Now

OGL 200

Auto Fan/auto Light
Fireman System / Mode.
LED Lights & Fan/Blower
Free Service For One Year.
Floor Announcement System.
Overload devies & Indicators.
Collective Selective Operation.
Levelling Accuracy Up To +/-2mm
Serial Link Communication Control
Quick Fix Trouble Shoot With Service Remote.
VF Door Operation with Infra Red Door Screen
Battery operated Emergency light & Alarm Bell
Call Registration Indication In Car & Hall Buttons.
Automatic Door Operation With Gearless Operator.
Dot Matrix Position Indication In Car And Hall Face Plases
Smooth Elevator Ride Comfort With Jerkfree Start Or Stop.
MS Power Coated Finish Cabin-With False Ceiling
MS Power Coated Finish Landing Doors with SS Frame.
Automatic Rescue Device Duing Power Cut-Off For Passenger Safety.
Germen Technology Gearless Traction Machine With Operating Speed upto 2.5Mps.

OLYMPIA ELEVATORS PVT. LTD.

Our Branches

Head Office

Head Office: S.NO.59/60,Shop No.03.A-Wing Mansarovar,
Annex,Kondhwa-Bk,Pune-411048

Dimensional Details OGL 200
Passenger Capacity	Speed	Travel Height	Shaft Size		Car Size		Entrance Size	Door Type	Pit Depth	Overhead Height
Passenger Capacity	Speed	Travel Height	Width	Depth	Width	Depth	Entrance Size	Door Type	Pit Depth	Overhead Height
3	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	1100	1200	750	600	600x2000	ACO	1350	4000
			1150	1225	750	625	600x2000	ACO
			1250	1250	750	650	600x2000	ACO
			1350	1275	750	675	600x2000	ACO
			1350	1330	750	700	600x2000	ATS
			1400	1355	750	725	600x2000	ATS
			1450	1380	750	750	600x2000	ATS
			1500	1405	750	775	600x2000	ATS
4	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	1250	1375	850	700	600x2000	ACO	1350	4000
			1350	1400	850	725	600x2000	ACO
			1400	1425	850	750	600x2000	ACO
			1450	1450	850	775	600x2000	ACO
			1500	1475	850	800	600x2000	ACO
			1550	1500	850	825	600x2000	ATS
			1600	1525	850	850	700x2000	ATS
			1650	1550	850	875	700x2000	ATS
5	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	1600	1575	950	800	700x2000	ATS	1350	4000
			1650	1600	950	825	700x2000	ACO
			1700	1625	950	850	700x2000	ACO
			1750	1650	950	875	700x2000	ATS
8	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	1800	1700	1050	900	800x2000	ATS	1500	4200
			1850	1725	1050	925	800x2000	ACO
			1900	1750	1050	950	800x2000	ACO
			1950	1775	1050	975	800x2000	ATS
10	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	2000	1800	1150	1000	800x2000	ATS	1600	4500
			2050	1825	1150	1025	800x2000	ACO
			2100	1850	1150	1050	800x2000	ACO
			2150	1875	1150	1075	800x2000	ATS
13	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	2200	1900	1250	1100	900x2000	ACO	1600	4500
			2250	1925	1250	1125	900x2000	ACO
			2300	1950	1250	1150	900x2000	ATS
			2350	1975	1250	1175	900x2000	ATS
15	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	2400	2000	1350	1200	900x2000	ACO	1800	4800
			2450	2025	1350	1225	900x2000	ACO
			2500	2050	1350	1250	900x2000	ACO
			2550	2075	1350	1275	900x2000	ATS
16	0.3 to 1.5 Mps Max	3 to 45 Mtr Max	2600	2100	1450	1300	1000x2000	ACO	1800	4800
			2650	2125	1450	1325	1000x2000	ACO
			2700	2150	1450	1350	1000x2000	ACO
			2750	2175	1450	1375	1000x2000	ATS

OGL 200

OLYMPIA ELEVATORS PVT. LTD.

Our Branches

Head Office

CONTROL PANEL

TOUCH TYPE LOP/COP

SERIAL LINK CONTROLLER

CAR OPERATING PANEL

GEARLESS ELEVATOR

CAR OPERATING PANEL

COP

GEARLESS MACHINE

LOP PANEL
